KSCAN-Magic

KSCAN-MAGIC is a high-speed handheld 3D scanner with five laser modes and built-in photogrammetry, delivering ultra-precise, marker-free scanning for large and detailed parts.

Product Description

KSCAN-MAGIC

The KSCAN-MAGIC is a professional-grade handheld 3D scanner designed for ultra-accurate, marker-free scanning across complex and large-scale objects. Combining five scanning modes with integrated photogrammetry, it delivers exceptional adaptability and speed for metrology, inspection, and reverse engineering tasks.

Five Scanning Modes for Maximum Flexibility

KSCAN-MAGIC offers unmatched versatility through its advanced multi-mode scanning system:

  • Ultra-Fast Mode – For rapid large-object scanning using blue laser crosses

  • Hyperfine Mode – For capturing detailed features with high resolution

  • Deep Hole Mode – Ideal for scanning grooves, holes, and recesses

  • Large-Area Infrared Mode – Perfect for capturing massive parts with parallel laser lines

  • Built-in Photogrammetry – Expands volume coverage and boosts accuracy over distance

Precision, Speed, and Control

Achieve accuracy up to 0.020 mm and resolution of 0.010 mm, with scanning speeds reaching 4,150,000 measurements per second. Whether inspecting high-precision components or reverse engineering assemblies, KSCAN-MAGIC ensures detailed, repeatable results.

KSCAN-MAGIC – Adaptable for Industrial Use

From reflective surfaces to dark finishes, KSCAN-MAGIC handles it all without the need for powder or markers. Optional modules such as probing, pipe inspection, and automated system compatibility further extend its capabilities across factory floors and production environments.

Real-World Applications

  • Aerospace: Fast inspection of airframes, brackets, and structural parts

  • Automotive: Quality assurance of panels, underbody, and dies

  • Defense: Reverse engineering of legacy components

  • Transportation & Mobility: On-site scanning of rail, marine, and vehicle systems

  • Energy, Process & Utilities: Inspection and digital replication of large redundant parts

KSCAN-MAGIC brochure cover showing handheld 3D scanner with laser lines

Review the Full Scanner Specs

The brochure includes key technical data, accuracy benchmarks, and example use cases. Helpful for evaluating fit across inspection, reverse engineering, and production tasks.
